9WL Splash Proof Fans

Sanyo Denki 9WL Splash Proof Fans are IP68-rated for water and dust resistance. These Sanyo Denki fans offer the longest lifespan and the highest air flow among same size industrial-use axial DC cooling fans. 9WL series offers an ideal cooling solution for PV inverters, quick chargers for electric vehicles, and LED panels. A PWM speed control function allows the user to set the rotational speed of the fan and helps to minimize power consumption and noise. The devices offer an operating supply voltage range of 12VDC to 48VDC, a speed range of 2300RPM to 17500RPM, and a power rating range of 1.2W to 23.04W.

Results: 132
Select Image Part #
 Mfr.
Description Datasheet Availability Pricing (EUR) Filter the results in the table by unit price based on your quantity.
Qty. RoHS ECAD Model Type
Height
Depth
Width
Operating Supply Voltage
Airflow
Speed
Bearing Type
Noise
IP Rating
Power Rating
Features
Housing Material
Termination Style
Series
Sanyo Denki DC Fans Fan, 80x80x25mm, 12VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
113In Stock
Min.: 1
Mult.: 1

Axial 80 mm 25 mm 80 mm 12 VDC 36.3 CFM (1.03 m3/min) 3700 RPM Ball 31 dBA IP68 1.44 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Axial Fan, 60x60x25mm, 24VDC, Splash/Dust Proof, Long Life 180Khr, Ribless, IP68
Datasheet
97In Stock
Min.: 1
Mult.: 1

Axial 60 mm 25 mm 60 mm 24 VDC 49.4 CFM (1.4 m3/min) 11000 RPM Ball 53 dBA IP68 8.16 W Splash Proof, Dust Proof Aluminum Wire Leads - 2 9WL Type
Sanyo Denki DC Fans Fan, 40x40x28mm, 24VDC, Splash/Dust Proof, 150Khr, Ribless, Tach/PWM, IP68
Datasheet
90In Stock
Min.: 1
Mult.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 19.7 CFM (0.56 m3/min) 15500 RPM Ball 47 dBA IP68 4.8 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 40x40x28mm, 24VDC, Splash/Dust Proof, 150Khr, Ribless, Tach/PWM, IP68
Datasheet
185In Stock
126Expected 24/08/2026
Min.: 1
Mult.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 22.2 CFM (0.63 m3/min) 17500 RPM Ball 51 dBA IP68 6.24 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 60x60x25mm, 24VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
74In Stock
Min.: 1
Mult.: 1

Axial 60 mm 25 mm 60 mm 24 VDC 38.8 CFM (1.1 m3/min) 8650 RPM Ball 47 dBA IP68 4.56 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 60x60x25mm, 24VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
54In Stock
320Expected 15/06/2026
Min.: 1
Mult.: 1

Axial 60 mm 25 mm 60 mm 24 VDC 49.4 CFM (1.4 m3/min) 11000 RPM Ball 53 dBA IP68 8.16 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 80x80x25mm, 12VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
25In Stock
Min.: 1
Mult.: 1

Axial 80 mm 25 mm 80 mm 12 VDC 54.3 CFM (1.54 m3/min) 5500 RPM Ball 43 dBA IP68 3.6 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 80x80x25mm, 12VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
75In Stock
Min.: 1
Mult.: 1

Axial 80 mm 25 mm 80 mm 12 VDC 73 CFM (2.1 m3/min) 7400 RPM Ball 49 dBA IP68 7.2 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x38mm, 12VDC, Splash/Dust Proof, 100Khr, Ribless, Tach/PWM, IP68
Datasheet
31In Stock
56Expected 15/06/2026
Min.: 1
Mult.: 1

Axial 92 mm 38 mm 92 mm 12 VDC 131 CFM (3.7 m3/min) 9000 RPM Ball 61 dBA IP68 22.8 W Tachometer, PWM Plastic Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x25mm, 24VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
41In Stock
Min.: 1
Mult.: 1

Axial 92 mm 25 mm 92 mm 24 VDC 59.7 CFM (1.69 m3/min) 3850 RPM Ball 37 dBA IP68 2.64 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x38mm, 48VDC, 130.6CFM, Splash Proof, 100Khr, Ribless, Tach/PWM, IP68
Datasheet
18In Stock
28Expected 30/07/2026
Min.: 1
Mult.: 1

Axial 92 mm 38 mm 92 mm 48 VDC 131 CFM (3.7 m3/min) 9000 RPM Ball 61 dBA IP68 23.04 W Tachometer, PWM Plastic Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 40x40x28mm, 12VDC, Splash/Dust Proof, 150Khr, Ribless, Tach/PWM, IP68
Datasheet
19In Stock
126Expected 15/06/2026
Min.: 1
Mult.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 22.2 CFM (0.63 m3/min) 17500 RPM Ball 51 dBA IP68 6.24 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 60x60x25mm, 12VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
4In Stock
80Expected 08/06/2026
Min.: 1
Mult.: 1

Axial 60 mm 25 mm 60 mm 12 VDC 38.8 CFM (1.1 m3/min) 8650 RPM Ball 47 dBA IP68 4.68 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x38mm, 24VDC, Splash/Dust Proof, 100Khr, Ribless, Tach/PWM, IP68
Datasheet
7In Stock
84On Order
Min.: 1
Mult.: 1

Axial 92 mm 38 mm 92 mm 24 VDC 131 CFM (3.7 m3/min) 9000 RPM Ball 61 dBA IP68 22.8 W Tachometer, PWM Plastic Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x25mm, 24VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
3In Stock
56On Order
Min.: 1
Mult.: 1

Axial 92 mm 25 mm 92 mm 24 VDC 77.7 CFM (2.2 m3/min) 5000 RPM Ball 44 dBA IP68 5.04 W Tachometer, PWM, Splash Proof, Dust Proof Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 140x140x51mm, 12VDC, Splash/Dust Proof, 100Khr, Ribless, Tach/PWM, IP68
Datasheet
7In Stock
12Expected 18/05/2026
Min.: 1
Mult.: 1

Axial 140 mm 51 mm 140 mm 12 VDC 212 CFM (6 m3/min) 5000 RPM Ball 57 dBA IP68 22 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 140x140x38mm, 24VDC, Splash/Dust Proof, Long Life, Ribless, Tach/PWM, IP68
Datasheet
14Expected 31/08/2026
Min.: 1
Mult.: 1

Axial 140 mm 38 mm 140 mm 24 VDC 282 CFM (8 m3/min) 6900 RPM Ball 68 dBA IP68 44.64 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 40x40x28mm, 12VDC, Splash/Dust Proof, 150Khr, Ribless, Tach/PWM, IP68
Datasheet
972On Order
Min.: 1
Mult.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 19.7 CFM (0.56 m3/min) 15500 RPM Ball 47 dBA IP68 4.8 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 60x60x25mm, 12VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
462On Order
Min.: 1
Mult.: 1

Axial 60 mm 25 mm 60 mm 12 VDC 49.4 CFM (1.4 m3/min) 11000 RPM Ball 53 dBA IP68 8.04 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 80x80x25mm, 24VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
200In Stock
Min.: 1
Mult.: 1

Axial 80 mm 25 mm 80 mm 24 VDC 73 CFM (2.1 m3/min) 7400 RPM Ball 48 dBA IP68 6.72 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 140x140x51mm, 24VDC, Splash/Dust Proof, 100Khr, Ribless, Tach/PWM, IP68
Datasheet
188On Order
Min.: 1
Mult.: 1

Axial 140 mm 51 mm 140 mm 24 VDC 318 CFM (9 m3/min) 7500 RPM Ball 69 dBA IP68 62 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x38mm, 12VDC, Splash/Dust Proof, 100Khr, Ribless, Tach/PWM, IP68
Datasheet
56Expected 05/08/2026
Min.: 1
Mult.: 1

Axial 92 mm 38 mm 92 mm 12 VDC 102 CFM (2.9 m3/min) 7000 RPM Ball 55 dBA IP68 11.4 W Tachometer, PWM Plastic Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 92x92x25mm, 12VDC, Splash/Dust Proof, 180Khr, Ribless, Tach/PWM, IP68
Datasheet
56Expected 29/07/2026
Min.: 1
Mult.: 1

Axial 92 mm 25 mm 92 mm 12 VDC 77.7 CFM (2.2 m3/min) 5000 RPM Ball 44 dBA IP68 5.04 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type
Sanyo Denki DC Fans Fan, 140x140x38mm, 12VDC, Splash/Dust Proof, Long Life, Ribless, Tach/PWM, IP68
Datasheet
14Expected 10/08/2026
Min.: 1
Mult.: 1

Axial 140 mm 38 mm 140 mm 12 VDC 282 CFM (8 m3/min) 6900 RPM Ball 68 dBA IP68 44.64 W Tachometer, PWM Aluminum Wire Leads - 4 9WL Type


Sanyo Denki DC Fans Axial Fan, 140x140x51mm, 24VDC, Splash/Dust Proof, Long Life 100K, Ribless, IP68
Datasheet
15On Order
Min.: 1
Mult.: 1

Axial 140 mm 51 mm 140 mm 24 VDC 173 CFM (4.9 m3/min) 4100 RPM Ball 52 dBA IP68 13.2 W Splash Proof, Dust Proof Aluminum Wire Leads - 2 9WL Type
