Infineon NovalithIC™ high current motor drivers pair a p-channel high-side switch and a n-channel low-side switch to create a half-bridge, adding an integrated circuit to protect the device. The IC also features microprocessor-compatible logic level inputs, diagnosis with current sense, slew rate adjustment and dead-time generation. Overtemperature, overvoltage, undervoltage, overcurrent and short-circuit protection is part of the package. Two hallmark features set this multichip, half-bridge configuration apart - it generates neither charge pump emissions nor cross-current. The half-bridge combines with others to form H-bridge and three-phase drive configurations.
Low path resistance down to 16mOhm and high-current capability up to 70A typical
Low quiescent current of 7μA
PWM capability up to 25kHz + active freewheeling
Switched-mode current limitation
Logic level inputs
Integrated over-/undervoltage, overtemperature, and overcurrent protection
Status flag diagnosis
Analog current sense
Adjustable slew rate
Fast switching speed, rise, and fall times of 500ns
Automation and Control
Infineon Technologies DCSHIELDBTN9970LVTOBO1 DC-Motor Control Shield
Ideally designed to enable and support the evaluation of the NovalithIC+™ family.
