Eaton EXL1V Power Inductors are magnetically shielded with low electromagnetic interference (EMI) and DC resistance (DCR) as well as high current-carrying capacity. Eaton EXL1V Inductors feature an iron powder core material with soft saturation. The series provides a 0.18μH to 10μH inductance range and a 4.4A to 36A current range. Typical applications include PC power systems and DC/DC converters.
High current-carrying capacity
Low DCR and high efficiency
Magnetically shielded, low EMI
Iron powder core material
Moisture Sensitivity Level (MSL) 1
PC power systems
150nHH to 15μH inductance range
5A to 36A maximum DC current range
1.75mΩ to 48.79mΩ maximum DC resistance range
5.4A to 32.5A saturation current range
5.1MHz to 140MHz self-resonant frequency range
-40°C to +125°C operating temperature range
Alloy powder core material
