Melexis MLX90372 Magnetic Field Sensors

Melexis MLX90372 Magnetic Field Sensors add stray field immunity to the Triaxis® family. Featuring a SENT or PWM output signal, the MLX90372 supports a wide variety of automotive position sensing applications, from powertrain actuators to human-machine interfaces. Melexis MLX90372 sensors offer substantial improvements over the previous generation. The stray field immune mode drastically reduces or eliminates the effect of stray fields from other magnets or current-carrying conductors found in electrified vehicles and supports both on-axis rotary or linear motion with a four-pole or two-pole magnet, respectively.

Features

Highly flexible and robust position sensor
Stray field immune (up to 4kA/m) mode of operation
SENT or PWM output
EMC capable of automotive OEM requirements
ASIL-C (SEooc) component

SOIC-8, single-die package
TSSOP-16, redundant dual-die package
DMP-4, single-die PCB-less package
In-application programmable
Ta = -40° ... 160°C

Applications

Automotive Powertrain
- Electric throttle body sensor
- Coolant valve sensor
- Turbo wastegate sensor
Human-Machine Interfaces
- Shifters (rotary knob and lever type)
- Selection (menu, volume) knobs

Automotive Transmission
- Clutch and fork position sensing
- Lever/slide switch linear stroke
Automotive Chassis & Safety
- Ride-height sensor
- Fuel level sensor
- Accelerator, brake, and clutch sensor
